Другие пластины этой серии
| Рис. | Наименование | Склад | Радиус RE | Обрабат. мат. | Сплав пластины | CW | Бренд | В корзину |
|---|---|---|---|---|---|---|---|---|
|
QPMG050204-DP-GM3220 | 872 | 0.4 | M | GM3220 | Ø16.0~Ø18.9 |
|
|
|
|
QPMG07T306-DP-GS4130 | 782 | 0.6 | M S | GS4130 | Ø22.6~Ø27.0 |
|
|
|
|
QPMG060204-DP-GS4130 | 736 | 0.4 | M S | GS4130 | Ø19.0~Ø22.5 |
|
|
|
|
QPMG040204-DP-GM3220 | 546 | 0.4 | M | GM3220 | Ø14.0~Ø15.9 |
|
|
|
|
QPMG07T306-DP-GA4230 | 510 | 0.6 | P M K | GA4230 | Ø22.6~Ø27.0 |
|
|
|
|
QPMG050204-DP-GS4130 | 480 | 0.4 | M S | GS4130 | Ø16.0~Ø18.9 |
|
|
|
|
QPMG040204-DP-GA4230 | 446 | 0.4 | P M K | GA4230 | Ø14.0~Ø15.9 |
|
|
|
|
QPMG07T306-DP-GM3220 | 417 | 0.6 | M | GM3220 | Ø22.6~Ø27.0 |
|
|
|
|
QPMG060204-DP-GA4230 | 400 | 0.4 | P M K | GA4230 | Ø19.0~Ø22.5 |
|
|
|
|
QPMG09T308-DP-GS4130 | 398 | 0.8 | M S | GS4130 | Ø27.1~Ø33.0 |
|
|
|
|
QPMG040204-DP-GS4130 | 303 | 0.4 | M S | GS4130 | Ø14.0~Ø15.9 |
|
|
|
|
QPMG09T308-DP-GM3220 | 270 | 0.8 | M | GM3220 | Ø27.1~Ø33.0 |
|
|
|
|
QPMG110408-DP-GM3220 | 248 | 0.8 | M | GM3220 | Ø33.1~Ø40.0 |
|
|
|
|
QPMG060204-DP-GM3220 | 222 | 0.4 | M | GM3220 | Ø19.0~Ø22.5 |
|
|
|
|
QPMG110408-DP-GA4230 | 150 | 0.8 | P M K | GA4230 | Ø33.1~Ø40.0 |
|
|
|
|
QPMG110408-DP-GS4130 | 138 | 0.8 | M S | GS4130 | Ø33.1~Ø40.0 |
|
|
|
|
QPMG130408-DP-GA4230 | 120 | 0.8 | P M K | GA4230 | Ø16.0~Ø18.9 |
|
|
|
|
QPMG130408-DP-GS4130 | 120 | 0.8 | M S | GS4130 | Ø16.0~Ø18.9 |
|
|
|
|
QPMG150512-DP-GA4230 | 114 | 1.2 | P M K | GA4230 | Ø45.1~Ø51.0 |
|
|
|
|
QPMG130408-DP-GM3220 | 100 | 0.8 | M | GM3220 | Ø16.0~Ø18.9 |
|
|
|
SPGT140512-PM-YBG205 | 90 | 1.2 | N | YBG205 | Ø42.0~Ø50.0 |
|
|
|
|
QPMG150512-DP-GM3220 | 50 | 1.2 | M | GM3220 | Ø45.1~Ø51.0 |
|
|
|
|
QPMG09T308-DP-GA4230 | 27 | 0.8 | P M K | GA4230 | Ø27.1~Ø33.0 |
|
|
|
|
SPGT07T308-EM-YBG212 | 10 | 0.8 | N | YBG212 | Ø22.6~Ø27.0 |
|
|
|
|
QPMG150512-DP-GS4130 | 0 | 1.2 | M S | GS4130 | Ø45.1~Ø51.0 |
|
|
|
|
QPMG050204-DP-GA4230 | 0 | 0.4 | P M K | GA4230 | Ø16.0~Ø18.9 |
|
