Расточка, точение профиля, выточки
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
GMT-QR40R10L10 | 0 | P M K S H | 4 | D4 (Ø4mm) | 50 | |
|
|
GMT-QR30R10L10 | 20 | P M K S H | 3 | D4 (Ø4mm) | 50 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
GMT-PR50R05L20 | 17 | P M K S H | 5 | D5 (Ø5mm) | 50 | |
|
|
GMT-PR40R20L08 | 20 | P M K S H | 4 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR30R20L06 | 16 | P M K S H | 3 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR40R10L22 | 132 | P M K S H | 4 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR80R15L30 | 69 | P M K S H | 8 | D8 (Ø8mm) | 60 | |
|
|
GMT-PR60R10L22 | 2 | P M K S H | 6 | D6 (Ø6mm) | 50 | |
|
|
GMT-PR20R10L06 | 100 | P M K S H | 2 | D4 (Ø4mm) | 40 | |
|
|
GMT-PR60R20L22 | 12 | P M K S H | 6 | D6 (Ø6mm) | 50 | |
|
|
GMT-PR60R10L15 | 0 | P M K | 6 | D6 (Ø6mm) | 50 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
MPR6-R0.2-L30 | 0 | P M K S H | 6.1 | D6 (Ø6mm) | 76 | |
|
|
MPR2-R0.1-L6 | 5 | P M K S H | 2.1 | D4 (Ø4mm) | 45 | |
|
|
MPR-3-R0.1-L15 | 20 | P M K S H | 3.1 | D4 (Ø4mm) | 50 | |
|
|
MPR4-R0.2-L10 | 1 | P M K S H | 4.1 | D4 (Ø4mm) | 50 | |
|
|
MPR4-R0.1-L15 | 0 | P M K S H | 4.1 | D4 (Ø4mm) | 50 | |
|
|
MPR5-R0.2-L22 | 7 | P M K S H | 5.1 | D5 (Ø5mm) | 50 | |
|
|
MPR-6-R0.2-L22 | 0 | P M K S H | 6.1 | D6 (Ø6mm) | 50 | |
|
|
MPR6-R0.2-L35 | 0 | P M K S H | 6.1 | D6 (Ø6mm) | 50 | |
|
|
MPR8-R0.2-L30 | 9 | P M K S H | 8 | D8 (Ø8mm) | 60 | |
|
|
MUR6-R0.15-L22 | 0 | P M K S H | 6.1 | D6 (Ø6mm) | 50 | |
|
|
MPR-6-R0.2-L15 | 35 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MPR-5-R0.2-L15 | 29 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MPR-4-R0.2-L15 | 20 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MPR-3-R0.2-L15 | 20 | P M K | 3.1 | D4 (Ø4mm) | 39 | |
|
|
MPR-3-R0.2-L10 | 20 | P M K | 3.1 | D4 (Ø4mm) | 39 | |
|
|
MPR-2-R0.2-L15 | 20 | P M K | 2.1 | D4 (Ø4mm) | 39 | |
|
|
MPR-2-R0.2-L10 | 20 | P M K | 2.1 | D4 (Ø4mm) | 39 | |
|
|
MPR-6-R0.1-L22 | 0 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MPR-6-R0.1-L15 | 36 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MPR-5-R0.1-L22 | 20 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MPR-5-R0.1-L15 | 17 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MPR-4-R0.1-L10 | 20 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MPR-3-R0.1-L10 | 1 | P M K | 3.1 | D4 (Ø4mm) | 39 | |
|
|
MPR-2-R0.1-L15 | 20 | P M K | 2.1 | D4 (Ø4mm) | 39 | |
|
|
MPR-2-R0.1-L10 | 15 | P M K | 2.1 | D4 (Ø4mm) | 39 | |
|
|
MPR3-R0.1-L22 | 16 | P M K | 3.1 | D3 (Ø3mm) | 47.3 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
MDQ4-R0.15-L22W | 6 | P M K S H | 4.1 | D4 (Ø4mm) | 50 | |
|
|
MQR6-R0.2-L22 | 0 | P M K S H | 6.1 | D6 (Ø6mm) | 50 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
GMT-PR10R05L04 | 0 | P M K | 1 | D4 (Ø4mm) | 40 | |
|
|
GMT-PR20R05L06 | 0 | P M K | 2 | D4 (Ø4mm) | 40 | |
|
|
GMT-PR30R10L10 | 4 | P M K | 3 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR30R10L15 | 0 | P M K | 3 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR30R20L15 | 20 | P M K | 3 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR40R05L08 | 30 | P M K | 4 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR40R20L22 | 20 | P M K | 4 | D4 (Ø4mm) | 50 | |
|
|
GMT-PR50R10L15 | 0 | P M K | 5 | D5 (Ø5mm) | 50 | |
|
|
GMT-PR50R10L22 | 15 | P M K | 5 | D5 (Ø5mm) | 50 | |
|
|
GMT-PR50R20L20 | 0 | P M K | 5 | D5 (Ø5mm) | 50 | |
|
|
GMT-PR60R05L20 | 0 | P M K | 6 | D6 (Ø6mm) | 50 | |
|
|
GMT-PR60R20L20 | 18 | P M K | 6 | D6 (Ø6mm) | 50 | |
|
|
GMT-PR80R30L30 | 0 | P M K | 8 | D8 (Ø8mm) | 60 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
GMT-QR40R20L10 | 0 | P M K | 4 | D4 (Ø4mm) | 50 | |
|
|
GMT-QR60R10L15 | 0 | P M K | 6 | D6 (Ø6mm) | 50 | |
|
|
GMT-QR80R10L25 | 10 | P M K | 8 | D8 (Ø8mm) | 60 | |
|
|
GMT-QR80R20L25 | 0 | P M K | 8 | D8 (Ø8mm) | 60 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
PR D1.7*R0.05*L6*d4 | 10 | P M K | 1.7 | D4 (Ø4mm) | 26.3 | |
|
|
PR D1.7*R0.05*L9*d4 | 10 | P M K | 1.7 | D4 (Ø4mm) | 26.3 | |
|
|
PR D2 R0.05 L6 | 6 | P M K | 2 | D4 (Ø4mm) | 26.3 | |
|
|
PR D2 R0.05 L9 | 6 | P M K | 2 | D4 (Ø4mm) | 26.3 | |
|
|
PR D2 R0.10 L13 | 0 | P M K | 2 | D4 (Ø4mm) | 32.3 | |
|
|
PR D2.2*R0.1*L13*d4 | 10 | P M K | 2.2 | D4 (Ø4mm) | 32.3 | |
|
|
PR D2.2*R0.1*L6*d4 | 0 | P M K | 2.2 | D4 (Ø4mm) | 27.3 | |
|
|
PR D2.5 R0.05 L10 | 0 | P M K | 2.5 | D4 (Ø4mm) | 27.5 | |
|
|
PR D2.7*R0.05*L15*d4 | 4 | P M K | 2.7 | D4 (Ø4mm) | 32.3 | |
|
|
PR D2.7*R0.15*L10*d4 | 9 | P M K | 2.7 | D4 (Ø4mm) | 27.3 | |
|
|
PR D3 R0.15 L10 | 6 | P M K | 3 | D4 (Ø4mm) | 27.3 | |
|
|
PR D3 R0.15 L15 | 6 | P M K | 3 | D4 (Ø4mm) | 32.3 | |
|
|
PR D3.2*R0.15*L10*d4 | 10 | P M K | 3.2 | D4 (Ø4mm) | 27.3 | |
|
|
PR D3.2*R0.15*L15*d4 | 11 | P M K | 3.2 | D4 (Ø4mm) | 32.3 | |
|
|
PR D4 R0.15 L10 | 10 | P M K | 4 | D4 (Ø4mm) | 42.3 | |
|
|
PR D4 R0.15 L25 | 0 | P M K | 4 | D4 (Ø4mm) | 42.3 | |
|
|
PR D4.2*R0.15*L10*d4 | 10 | P M K | 4.2 | D4 (Ø4mm) | 27.3 | |
|
|
PR D4.2*R0.15*L15*d4 | 9 | P M K | 4.2 | D4 (Ø4mm) | 32.3 | |
|
|
PR D4.2*R0.15*L20*d4 | 8 | P M K | 4.2 | D4 (Ø4mm) | 37.3 | |
|
|
PR D5 R0.2 L30 | 0 | P M K | 5 | D5 (Ø5mm) | 51.3 | |
|
|
PR D5.2*R0.2*L10*d5 | 0 | P M K | 5.2 | D5 (Ø5mm) | 32.3 | |
|
|
PR D5.2*R0.2*L15*d5 | 5 | P M K | 5.2 | D5 (Ø5mm) | 37.3 | |
|
|
PR D5.2*R0.2*L20*d5 | 10 | P M K | 5.2 | D5 (Ø5mm) | 42.3 | |
|
|
PR D5.2*R0.2*L25*d5 | 10 | P M K | 5.2 | D5 (Ø5mm) | 47.3 | |
|
|
PR D6.2*R0.2*L15*d6 | 9 | P M K | 6.2 | D6 (Ø6mm) | 37.3 | |
|
|
PR D6.2*R0.2*L20*d6 | 10 | P M K | 6.2 | D6 (Ø6mm) | 42.3 | |
|
|
PR D6.2*R0.2*L25*d6 | 9 | P M K | 6.2 | D6 (Ø6mm) | 47.3 | |
|
|
PR D6.2*R0.2*L30*d6 | 8 | P M K | 6.2 | D6 (Ø6mm) | 52.3 | |
|
|
PR D6.2*TPR0.2*L40*d6 | 0 | P M K | 6.2 | D6 (Ø6mm) | 62.3 | |
|
|
PR D7 R0.2 L25 | 8 | P M K | 7 | D7 (Ø7mm) | 47.3 | |
|
|
PR D7 R0.2 L30 | 3 | P M K | 7 | D7 (Ø7mm) | 53.3 | |
|
|
PR D7 R0.2 L50 | 0 | P M K | 7 | D7 (Ø7mm) | 72.5 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
SBDR60150R020-D6 | 5 | P M K | 6 | D6 (Ø6mm) | 60 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
MQR-5-R0.2-L22 | 12 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MQR-5-R0.2-L15 | 0 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MQR-4-R0.2-L15 | 6 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MQR-4-R0.2-L10 | 6 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MQR-6-R0.1-L15 | 12 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MQR-5-R0.1-L22 | 20 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MQR-5-R0.1-L15 | 21 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MQR-4-R0.1-L15 | 24 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MQR-4-R0.1-L10 | 20 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MQR-6-R0.2-L15 | 0 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MQR4-R0.2-L22 | 0 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MQR6-R0.2-L30 | 0 | P M K | 6.1 | D6 (Ø6mm) | 58 | |
|
|
MQR4-R0.15-L22 | 25 | P M K | 4.1 | D4 (Ø4mm) | 51 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
MUR-6-R0.2-L22 | 0 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MUR-5-R0.2-L22 | 20 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MUR-4-R0.2-L10 | 20 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MUR-3-R0.1-L15 | 20 | P M K | 3.1 | D4 (Ø4mm) | 39 |
| Рис. | Наименование | Cклад | Обрабат. мат. | Min Dia | D | L2 | В корзину |
|---|---|---|---|---|---|---|---|
|
|
MUR-6-R0.1-L22 | 20 | P M K | 6.1 | D6 (Ø6mm) | 51 | |
|
|
MUR-5-R0.1-L22 | 19 | P M K | 5.1 | D6 (Ø6mm) | 51 | |
|
|
MUR-4-R0.1-L10 | 20 | P M K | 4.1 | D4 (Ø4mm) | 51 | |
|
|
MUR-3-R0.05-L15 | 20 | P M K | 3.1 | D4 (Ø4mm) | 39 |
