Для сквозных отверстий
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| 16130020 | 10 |
|
M2 | 0.40 | 14 | 46 | 2.8 | 2 | |
| 16 330 020 |
|
M2 | 0.40 | 45 | 2.8 | 2.1 | |||
| 16 630 020 |
|
M2 | 0.40 | 45 | 2.8 | 2.1 | |||
| 16130025 TICN | 0 |
|
M2.5 | 0.45 | 8 | 52 | 2.8 | 2 | |
| 16 160 025 |
|
M2.5 | 0.45 | 5 | 52 | 2.8 | 2 | ||
| 1780 0001 | 0 |
|
M3 | 0.50 | 56 | 3.5 | 2.7 | ||
| 16600030 | 5 |
|
M3 | 0.50 | 56 | 3.5 | 2.7 | ||
| 17220030 | 3 |
|
M3 | 0.50 | 56 | 3.5 | 2.7 | ||
| 1750_0030 | 3 |
|
M3 | 0.50 | 70 | 2.2 | |||
| 16630040 | 3 |
|
M4 | 0.70 | 70 | 4.5 | 3.4 | ||
| 16 100 050 |
|
M5 | 0.80 | 22 | 52 | 6 | 4.8 | ||
| 16 130 060 |
|
M6 | 1.00 | 36 | 82.5 | 6 | 4.8 | ||
| 97700080-М8-1.25 | 0 |
|
M8 | 1.25 | 14 | 93 | 8 | 6.2 | |
| 16 130 016 | 1 |
|
M1.6 | 0.35 | 12 | 41 | 2.5 | 2 | |
| 1613 0016 | 9 |
|
M1.6 | 0.35 | 9 | 41 | 2.5 | 2 | |
| 97700030 | 0 |
|
M3 | 0.50 | 5 | 57 | 3.5 | 2.7 | |
| 97140030 | 0 |
|
M3 | 0.50 | 10 | 57 | 3.5 | 2.7 | |
| C843285 | 8 |
|
M3 | 0.50 | 12 | 59 | 3.5 | 2.7 | |
| 97140050 | 0 |
|
M5 | 0.80 | 15 | 72 | 6 | 4.9 | |
| C843287 | 11 |
|
M5 | 0.80 | 18 | 75 | 6 | 4.9 | |
| 97700050 | 0 |
|
M5 | 0.80 | 9 | 72 | 6 | 4.9 | |
| 97140060 | 6 |
|
M6 | 1.00 | 18 | 82 | 6 | 4.9 | |
| C843289 | 0 |
|
M6 | 1.00 | 21 | 86 | 6 | 4.9 | |
| 97700060 | 0 |
|
M6 | 1.00 | 11 | 82 | 6 | 4.9 | |
| 97700080 | 0 |
|
M8 | 1.25 | 14 | 93 | 8 | 6.3 | |
| 97140080 | 10 |
|
M8 | 1.25 | 14 | 93 | 8 | 6.3 | |
| C843290 | 3 |
|
M8 | 1.25 | 24 | 94 | 8 | 6.3 | |
| C843292 | 30 |
|
M12 | 1.75 | 30 | 110 | 9 | 7 | |
| 97140120 | 1 |
|
M12 | 1.75 | 24 | 110 | 9 | 7 | |
| C843291 | 26 |
|
M10 | 1.50 | 26 | 105 | 10 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M3х0.5 HSS |
|
M3 | 0.50 | 10 | 44.5 | 3.4 | 2.6 | ||
| M3x0.5 HSSE | 1 |
|
M3 | 0.50 | 14 | 43 | 3.5 | 2.6 | |
| VO-27330 | 3 |
|
M4 | 0.70 | 13 | 45 | 4.5 | 3.4 | |
| VO-27334 | 4 |
|
M5 | 0.80 | 16 | 50 | 6 | 4.9 | |
| VO-57338 | 2 |
|
M6 | 1.00 | 19 | 50 | 6 | 4.9 | |
| M12x0.5, DIN 218 | 2 |
|
M12 | 0.50 | 22 | 70 | 9 | 7 | |
| GM-TF120125 | 1 |
|
M12 | 1.25 | 22 | 70 | 7 | ||
| VO-27340 | 2 |
|
M7 | 1.00 | 19 | 50 | 6 | 4.9 | |
| VO-26330 | 1 |
|
M9 | 1.00 | 20 | 63 | 7 | 5.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | В корзину |
|---|---|---|---|---|---|---|---|---|
| 4222M-M4-0.5-6H-KTG402 |
|
M4 | 0.70 | 8 | 63 | 4.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM71-41-03050 | 135 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| PM71-41-04070 | 150 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| PM71-41-05080 | 128 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| PM71-41-06100 | 100 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| PM71-41-08125 | 97 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| PM76-41-12175 | 70 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| PM76-41-16200 | 68 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| PM71-41-10150 | 100 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| PM76-41-14200 | 9 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 | |
| PM76-41-18250 | 5 |
|
M18 | 2.50 | 37 | 125 | 14 | 11 | |
| PM76-41-20250 | 4 |
|
M20 | 2.50 | 37 | 140 | 16 | 12 | |
| MS31-03050 | 0 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| MS31-04070 | 58 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| MS31-05080 | 29 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| MS31-06100 | 2 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| MS31-08125 | 22 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| MS31-08100 | 8 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| MS31-12100 | 10 |
|
M12 | 1.00 | 22 | 110 | 9 | 7 | |
| MS31-12150 | 0 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| MS31-12125 | 4 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| MS31-12175 | 68 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| MS31-16200 | 0 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| MS31-16150 | 0 |
|
M16 | 1.50 | 32 | 110 | 12 | 9 | |
| MS31-24300 | 2 |
|
M24 | 3.00 | 45 | 160 | 18 | 14.5 | |
| MS31-24150 | 5 |
|
M24 | 1.50 | 45 | 160 | 18 | 14.5 | |
| MS31-10100 | 10 |
|
M10 | 1.00 | 24 | 100 | 10 | 8 | |
| MS31-10125 | 8 |
|
M10 | 1.25 | 24 | 100 | 10 | 8 | |
| MS31-10150 | 76 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| MS31-14200 | 17 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 | |
| MS31-14150 | 1 |
|
M14 | 1.50 | 30 | 110 | 11 | 9 | |
| MS31-18250 | 4 |
|
M18 | 2.50 | 37 | 125 | 14 | 11 | |
| MS31-18150 | 0 |
|
M18 | 1.50 | 37 | 125 | 14 | 11 | |
| MS31-20150 | 2 |
|
M20 | 1.50 | 37 | 140 | 16 | 12 | |
| MS31-20250 | 4 |
|
M20 | 2.50 | 37 | 140 | 16 | 12 | |
| MS31-22250 | 1 |
|
M22 | 2.50 | 38 | 140 | 18 | 14.5 | |
| MS31-22150 | 0 |
|
M22 | 1.50 | 38 | 140 | 18 | 14.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM71-31-03050 | 134 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| PM71-31-04070 | 122 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| PM71-31-05080 | 101 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| PM71-31-06100 | 90 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| PM71-31-08125 | 126 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| PM74-31-08100 | 15 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| PM74-31-12100 | 0 |
|
M12 | 1.00 | 22 | 110 | 9 | 7 | |
| PM74-31-12150 | 15 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| PM76-31-12175 | 72 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| PM74-31-12125 | 5 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| PM74-31-10100 | 10 |
|
M10 | 1.00 | 24 | 100 | 10 | 8 | |
| PM74-31-10125 | 10 |
|
M10 | 1.25 | 24 | 100 | 10 | 8 | |
| PM71-31-10150 | 79 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| PM74-31-14150 | 9 |
|
M14 | 1.50 | 30 | 110 | 11 | 9 | |
| MS21-03050 | 1 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| MS21-04070 | 19 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| MS21-05080 | 0 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| MS21-06100 | 12 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| MS21-08125 | 6 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| MS21-08100 | 6 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| MS21-12125 | 5 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| MS21-12150 | 0 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| MS21-12175 | 23 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| MS21-12100 | 10 |
|
M12 | 1.00 | 22 | 110 | 9 | 7 | |
| MS21-16150 | 0 |
|
M16 | 1.50 | 32 | 110 | 12 | 9 | |
| MS21-16200 | 0 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| MS21-24300 | 0 |
|
M24 | 3.00 | 45 | 160 | 18 | 14.5 | |
| MS21-24150 | 0 |
|
M24 | 1.50 | 45 | 160 | 18 | 14.5 | |
| MS21-10150 | 25 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| MS21-10100 | 7 |
|
M10 | 1.00 | 24 | 100 | 10 | 8 | |
| MS21-10125 | 10 |
|
M10 | 1.25 | 24 | 100 | 10 | 8 | |
| MS21-14150 | 0 |
|
M14 | 1.50 | 30 | 110 | 11 | 9 | |
| MS21-14200 | 0 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 | |
| MS21-18250 | 0 |
|
M18 | 2.50 | 37 | 125 | 14 | 11 | |
| MS21-18150 | 0 |
|
M18 | 1.50 | 37 | 125 | 14 | 11 | |
| MS21-20250 | 0 |
|
M20 | 2.50 | 37 | 140 | 16 | 12 | |
| MS21-20150 | 0 |
|
M20 | 1.50 | 37 | 140 | 16 | 12 | |
| MS21-22150 | 0 |
|
M22 | 1.50 | 38 | 140 | 18 | 14.5 | |
| MS21-22250 | 0 |
|
M22 | 2.50 | 38 | 140 | 18 | 14.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM71-41-02040 | 97 |
|
M2 | 0.40 | 8 | 45 | 2.8 | 2.1 | |
| PM71-31-02040 | 145 |
|
M2 | 0.40 | 8 | 45 | 2.8 | 2.1 | |
| PM71-41-02545 | 100 |
|
M2.5 | 0.45 | 9 | 50 | 2.8 | 2.1 | |
| PM71-31-02545 | 150 |
|
M2.5 | 0.45 | 9 | 50 | 2.8 | 2.1 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| JIS-M2.5-TiСN-HSS-E | 199 |
|
M2.5 | 0.45 | 14 | 44 | 3 | 2.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM77-31-03050 | 20 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| PM77-31-04070 | 13 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| PM77-31-05080 | 20 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| PM77-31-06100 | 8 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| PM77-31-10150 | 8 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM78-31-12175 | 7 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M730-H33-040070 | 7 |
|
M4 | 0.70 | 9 | 63 | 4.5 | 3.4 | |
| M730-H33-050080 | 11 |
|
M5 | 0.80 | 10 | 70 | 6 | 4.9 | |
| M730-H33-060100 | 12 |
|
M6 | 1.00 | 10 | 80 | 6 | 4.9 | |
| M730-H33-080125 | 17 |
|
M8 | 1.25 | 13 | 90 | 8 | 6.2 | |
| M730-H33-120175 | 24 |
|
M12 | 1.75 | 17 | 110 | 9 | 7 | |
| M730-H33-160200 | 7 |
|
M16 | 2.00 | 20 | 110 | 12 | 9 | |
| M730-H33-100150 | 28 |
|
M10 | 1.50 | 15 | 100 | 10 | 8 | |
| M730-H33-140200 | 15 |
|
M14 | 2.00 | 20 | 110 | 11 | 9 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M720-H21-070100 | 175 |
|
M7 | 1.00 | 19 | 80 | 7 | 5.5 | |
| M720-H21-090125 | 173 |
|
M9 | 1.25 | 22 | 100 | 9 | 8 | |
| M720-H21-020040 | 0 |
|
M2 | 0.40 | 8 | 45 | 2.8 | 2.1 | |
| M720-H21-030050 | 1 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| M720-H21-040070 | 91 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| M720-H21-050080 | 290 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| M720-H21-060100 | 19 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| M720-H21-080125 | 10 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| M720-H21-100150 | 23 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M721-H21-120175 | 1 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| M721-H21-160200 | 0 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| M721-H21-140200 | 0 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| TC622206 | 1 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| TC622246 | 0 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| TR873316 | 0 |
|
M6 | 1.00 | 17 | 80 | 6 | 4.9 | |
| TC622366 | 0 |
|
M8 | 1.25 | 20 | 90 | 8 | 6.2 | |
| TM923606 | 0 |
|
M16 | 2.00 | 27 | 110 | 12 | 9 | |
| TC622426 | 0 |
|
M10 | 1.50 | 22 | 100 | 10 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|
| T7109139 | 0 |
|
M2 | 0.40 | 40 | 2.1 | ||
| TQ863176 | 0 |
|
M2.5 | 0.45 | 50 | |||
| TB623206 | 2 |
|
M3 | 0.50 | 56 | 3.5 | ||
| TC163206 | 5 |
|
M3 | 0.50 | 56 | 2.5 | ||
| T7109209 | 0 |
|
M3 | 0.50 | 40 | 2.7 | ||
| TRJ03316 | 0 |
|
M6 | 1.00 | 8 | |||
| TB623316 | 10 |
|
M6 | 1.00 | 80 | 6 | ||
| TRJ03366 | 7 |
|
M8 | 1.25 | 90 | 8 | ||
| TB623366 | 7 |
|
M8 | 1.25 | 90 | 8 | ||
| TB623506 | 8 |
|
M12 | 1.75 | 110 | 9 | ||
| TC814606 | 2 |
|
M16 | 2.00 | 110 | 12 | ||
| TB623606 | 4 |
|
M16 | 2.00 | 110 | 13 | ||
| TRJ03786 | 1 |
|
M24 | 3.00 | 160 | 18 | ||
| TB623426 | 0 |
|
M10 | 1.50 | 100 | |||
| TQ813426 | 7 |
|
M10 | 1.25 | 100 | 10 | ||
| TRJ03706 | 2 |
|
M20 | 2.50 | 140 | 16 |
