Для глухих отверстий
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| MM892C_M6.1_NR35-P6M5.1 | 0 |
|
M6 | 1.00 | 21 | 86 | 4.5 | 3.4 | |
| JIS-M2-TiСN-HSSE | 0 |
|
M2 | 0.40 | 3.2 | 40 | 3 | 2.5 | |
| 17250020 | 0 |
|
M2 | 0.40 | 6 | 46 | 2.8 | 2 | |
| 16430020 | 0 |
|
M2 | 0.40 | 45 | 2.8 | 2.1 | ||
| JIS-M2-HSSE | 48 |
|
M2 | 0.40 | 8 | 46 | 3 | 2.4 | |
| ZET-B P2M2X0.4 | 1 |
|
M2 | 0.40 | 12 | 42 | 3 | 2.5 | |
| 16160020 | 15 |
|
M2 | 0.40 | 11 | 46 | 2.8 | 2 | |
| 17250025 | 0 |
|
M2.5 | 0.45 | 50 | 2.8 | 2.1 | ||
| JIS-M2.5-HSSE | 0 |
|
M2.5 | 0.45 | 10 | 46 | 3 | 2.4 | |
| 17250030 | 6 |
|
M3 | 0.50 | 56 | 3.5 | 2.7 | ||
| DIN371-M3*0.5-HSSPM | 16 |
|
M3 | 0.50 | 7.5 | 58.5 | 3.3 | 2.7 | |
| 16640030 | 1 |
|
M3 | 0.50 | 56 | 3.5 | 2.7 | ||
| 16670030 | 0 |
|
M3 | 0.50 | 56 | 3.5 | 2.7 | ||
| DIN371-M4X0.7-HSSPM | 14 |
|
M4 | 0.70 | 12 | 66 | 4.5 | 3.4 | |
| TA02005 | 9 |
|
M5 | 0.80 | 20 | 64 | 5.5 | 4.5 | |
| DIN371-M5X0.8-HSSPM | 12 |
|
M5 | 0.80 | 9 | 74 | 6 | 5 | |
| 16670050 | 0 |
|
M5 | 0.80 | 70 | 6 | 4.9 | ||
| 1796 0005 | 0 |
|
M5 | 0.50 | 70 | 3.5 | 2.7 | ||
| 16430050 | 24 |
|
M5 | 0.80 | 70 | 6 | 4.9 | ||
| HSSEX FH2 SFT M5x0.8 | 9 |
|
M5 | 0.80 | 17 | 65.5 | 5.4 | 4.4 | |
| M5 Fplus 16640050 | 26 |
|
M5 | 0.80 | 70 | 6 | 4.9 | ||
| M6 Fplus 16430060 | 1 |
|
M6 | 1.00 | 80 | 6 | 4.9 | ||
| TA02006-Left | 30 |
|
M6 | 1.00 | 22 | 66 | 6 | 4.5 | |
| DIN371-M6X0.5-HSSPM | 1 |
|
M6 | 0.50 | 11 | 84.5 | 6 | 4.8 | |
| HSSEX FH2 M6x1.0 | 25 |
|
M6 | 1.00 | 20 | 62.5 | 6 | 4.4 | |
| 16670060 | 0 |
|
M6 | 1.00 | 80 | 6 | 4.9 | ||
| DIN371-M6X0.75-HSSPM | 1 |
|
M6 | 0.75 | 11 | 84.5 | 6 | 4.8 | |
| 1796 0015 |
|
M8 | 1.00 | 90 | 6 | 4.9 | |||
| TA02008-Left | 20 |
|
M8 | 1.25 | 20 | 69 | 6.3 | 4.9 | |
| 16430080 | 1 |
|
M8 | 1.25 | 90 | 8 | 6.2 | ||
| 16640080 | 2 |
|
M8 | 1.25 | 90 | 8 | 6.2 | ||
| 16670080 | 0 |
|
M8 | 1.25 | 90 | 8 | 6.2 | ||
| М12х1,75 |
|
M12 | 1.75 | 19 | 108 | 9 | 7 | ||
| DIN376-M12X1.75-HSSPM | 2 |
|
M12 | 1.75 | 18 | 110 | 9 | 7 | |
| 16430120 | 2 |
|
M12 | 1.75 | 110 | 9 | 7 | ||
| 16650120 | 0 |
|
M12 | 1.75 | 110 | 9 | 7 | ||
| SZ816016-M12 | 21 |
|
M12 | 1.25 | 21 | 88.7 | 9 | 7 | |
| DIN376-M16X2-HSSPM | 1 |
|
M16 | 2.00 | 22 | 110 | 12 | 9 | |
| TA02010 | 5 |
|
M10 | 1.50 | 24 | 80 | 8 | 6.3 | |
| DIN371-M10X1.5-HSSPM | 1 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| 16640100 | 1 |
|
M10 | 1.50 | 20 | 100 | 10 | 8 | |
| DIN376-M14X2-HSSPM | 2 |
|
M14 | 2.00 | 22 | 110 | 11 | 9 | |
| M14x1.5-S-TiCN C-PMK | 1 |
|
M14 | 1.50 | 20 | 95 | 11 | 9 | |
| D4-50G901-0145 | 1 |
|
M14 | 1.50 | 20.5 | 100 | 11 | 8.9 | |
| 376M18-6H-HSSE | 4 |
|
M18 | 2.50 | 21 | 110.5 | 14 | 11.2 | |
| TA0202015 HSS-E M20x1.5 6H TiALN (TICN-C) | 0 |
|
M20 | 1.50 | 21 | 112 | 14 | 11.2 | |
| JIS-M1.6-HSSE | 13 |
|
M1.6 | 0.35 | 8 | 38 | 3 | 2.4 | |
| 17250016 | 0 |
|
M1.6 | 0.35 | 40 | 2.5 | 2.1 | ||
| 16160016 | 10 |
|
M1.6 | 0.35 | 9 | 41 | 2.5 | 2 | |
| JIS-M1.6-TiСN-HSSE | 0 |
|
M1.6 | 0.35 | 8 | 38 | 3 | 2.4 | |
| TAG02014 | 0 |
|
G1/4 | 19 tpi | 19 | 95 | 11.2 | 9.0 | |
| 17990005 | 0 |
|
G3/8 | 19 tpi | 100 | 12 | 9 | ||
| NSP-M1-0.25-P1 | 0 |
|
M1 | 6 | 36 | 3 | 2.4 | ||
| TSP-SUS-M3-0.5-GT6 | 21 |
|
M3 | 0.50 | 5.5 | 49 | 4 | 3.1 | |
| 97710040 | 0 |
|
M4 | 0.70 | 7 | 65 | 4.5 | 3.4 | |
| TSP-SUS-M4-0.7-GT6 | 0 |
|
M4 | 0.70 | 8 | 55 | 5 | 3.9 | |
| MM892C-M5.1-NR35-P6M5TIN | 3 |
|
M5 | 0.80 | 17 | 75 | 3.5 | 2.7 | |
| MM892C-M5.1-NR35-P6M5 | 3 |
|
M5 | 0.80 | 17 | 75 | 3.5 | 2.7 | |
| TSP-SUS-M5-0.8-GT6 | 45 |
|
M5 | 0.80 | 10 | 65 | 5.5 | 4.5 | |
| 371M5-0.8-6H-HSSE | 3 |
|
M5 | 0.80 | 12 | 75 | 6 | 4.9 | |
| HSSEX-FH2-M5-0.8 | 5 |
|
M5 | 0.80 | 18 | 65 | 5.5 | 4.5 | |
| 97710050 | 4 |
|
M5 | 0.80 | 8 | 72 | 6 | 4.9 | |
| TSP-SUS-M6-1-GT6 | 40 |
|
M6 | 1.00 | 11 | 67 | 6 | 4.5 | |
| EX-SFT-M6-1-OH2 | 2 |
|
M6 | 1.00 | 21 | 67 | 6 | 4.5 | |
| MM892C-M6.1-NR35-P6M5TIN | 4 |
|
M6 | 1.00 | 21 | 86 | 4.5 | 3.4 | |
| HSSEX-FH2-M6-1.0-B | 17 |
|
M6 | 1.00 | 21 | 67 | 6 | 4.5 | |
| 97710060 | 14 |
|
M6 | 1.00 | 10 | 82 | 6 | 4.9 | |
| MM892C-M6.1-NR35-P6M5 | 3 |
|
M6 | 1.00 | 21 | 86 | 4.5 | 3.4 | |
| TSP-SUS-M8-1.25-GT7 | 0 |
|
M8 | 1.25 | 14 | 70 | 6.2 | 4.9 | |
| TSP-SUS-M12-1.75-GT8 | 2 |
|
M12 | 1.75 | 20 | 75 | 8.5 | 6.5 | |
| 376M12-1.75-6H-HSSE | 1 |
|
M12 | 1.75 | 23 | 110 | 9 | 7 | |
| 97710120 | 0 |
|
M12 | 1.75 | 18 | 110 | 9 | 7 | |
| 97700100 | 0 |
|
M10 | 1.50 | 15 | 100 | 10 | 8 | |
| 97710100 | 2 |
|
M10 | 1.50 | 15 | 100 | 10 | 8 | |
| 97710016 | 1 |
|
M1.6 | 0.35 | 13 | 40 | 2.5 | 2 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | В корзину |
|---|---|---|---|---|---|---|---|---|
| 4202C-M8-1.25-6H |
|
M8 | 1.25 | 22 | 90 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| ET138-SJN-020040C-P2 | 0 |
|
M2 | 0.40 | 11 | 45 | 3 | 2.5 | |
| ET138-SJN-025045C-P2 | 5 |
|
M2.5 | 0.45 | 12 | 45 | 3 | 2.5 | |
| ET138-SJN-030050C-P2 | 0 |
|
M3 | 0.50 | 5 | 50 | 4 | 3.2 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| ET168-SJN-020040C-P2 | 30 |
|
M2 | 0.40 | 11 | 45 | 3 | 2.5 | |
| ET168-SJN-025045C-P2 | 0 |
|
M2.5 | 0.45 | 12 | 45 | 3 | 2.5 | |
| ET168-SJN-030050C-P2 | 4 |
|
M3 | 0.50 | 5 | 50 | 4 | 3.2 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| ET166-SJN-060100C-P2 | 0 |
|
M6 | 1.00 | 12 | 69 | 6 | 4.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PQSU3RU040070P2Y90X | 5 |
|
M4 | 0.70 | 9 | 57 | 5 | 4 | |
| PQSU3RU050080P2Y90X | 38 |
|
M5 | 0.80 | 8 | 66 | 5.5 | 4.5 | |
| PQSU3RU060100P2Y90X | 9 |
|
M6 | 1.00 | 12 | 69 | 6 | 4.5 | |
| PQSU3RU080125P3Y90X | 6 |
|
M8 | 1.25 | 13 | 70 | 6.2 | 5 | |
| PQSU3RU120175P4Y90X | 10 |
|
M12 | 1.75 | 17 | 82 | 8.5 | 6.5 | |
| ET168-SJN-160200C-P5 | 3 |
|
M16 | 2.00 | 20 | 12.5 | |||
| PQSU3RU160200P5Y90X | 7 |
|
M16 | 2.00 | 20 | 95 | 12.5 | 10 | |
| PQSU3RU100150P4Y90X | 19 |
|
M10 | 1.50 | 15 | 75 | 7 | 5.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM81-41-03050 | 452 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| PM81-41-04070 | 264 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| PM81-41-05080 | 265 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| PM81-41-06100 | 190 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| PM81-41-08125 | 164 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| PM84-41-08100 | 45 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| PM84-41-12100 | 5 |
|
M12 | 1.00 | 22 | 110 | 9 | 7 | |
| PM86-41-12175 | 142 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| PM84-41-12150 | 20 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| PM84-41-12125 | 5 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| PM86-41-16200 | 70 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| PM84-41-24150 | 5 |
|
M24 | 1.50 | 45 | 160 | 18 | 14.5 | |
| PM86-41-24300 | 5 |
|
M24 | 3.00 | 45 | 160 | 18 | 14.5 | |
| PM84-41-10100 | 59 |
|
M10 | 1.00 | 24 | 100 | 10 | 8 | |
| PM84-41-10125 | 20 |
|
M10 | 1.25 | 24 | 100 | 10 | 8 | |
| PM81-41-10150 | 145 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| PM86-41-14200 | 50 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 | |
| PM84-41-14150 | 37 |
|
M14 | 1.50 | 30 | 110 | 11 | 9 | |
| PM86-41-18250 | 5 |
|
M18 | 2.50 | 37 | 125 | 14 | 11 | |
| PM84-41-18150 | 5 |
|
M18 | 1.50 | 37 | 125 | 14 | 11 | |
| PM86-41-20250 | 5 |
|
M20 | 2.50 | 37 | 140 | 16 | 12 | |
| PM86-41-22250 | 3 |
|
M22 | 2.50 | 38 | 140 | 18 | 14.5 | |
| PM84-41-22150 | 5 |
|
M22 | 1.50 | 38 | 140 | 18 | 14.5 | |
| MG31-03050 | 30 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| MG31-04070 | 2 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| MG31-05080 | 70 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| MG31-06100 | 114 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| MG31-08125 | 0 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| MG31-08100 | 0 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| MG31-12150 | 20 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| MG31-12175 | 50 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| MG31-12125 | 11 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| MG31-12100 | 17 |
|
M12 | 1.00 | 22 | 110 | 9 | 7 | |
| MG31-16150 | 9 |
|
M16 | 1.50 | 32 | 110 | 12 | 9 | |
| MG31-16200 | 18 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| MG31-24300 | 8 |
|
M24 | 3.00 | 45 | 160 | 18 | 14.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM81-31-03050 | 0 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| PM81-31-05080 | 0 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| PM81-31-06100 | 0 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| PM81-31-08125 | 0 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| PM84-31-08100 | 30 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| PM84-31-12125 | 5 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| PM86-31-12175 | 0 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| PM84-31-12150 | 61 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| PM86-31-16200 | 0 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| PM84-31-24150 | 15 |
|
M24 | 1.50 | 45 | 160 | 18 | 14.5 | |
| PM86-31-24300 | 5 |
|
M24 | 3.00 | 45 | 160 | 18 | 14.5 | |
| PM84-31-10100 | 100 |
|
M10 | 1.00 | 24 | 100 | 10 | 8 | |
| PM81-31-10150 | 0 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 | |
| PM84-31-10125 | 50 |
|
M10 | 1.25 | 24 | 100 | 10 | 8 | |
| PM86-31-14200 | 0 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 | |
| PM84-31-18150 | 10 |
|
M18 | 1.50 | 37 | 125 | 14 | 11 | |
| PM86-31-18250 | 0 |
|
M18 | 2.50 | 37 | 125 | 14 | 11 | |
| PM86-31-20250 | 0 |
|
M20 | 2.50 | 37 | 140 | 16 | 12 | |
| PM86-31-22250 | 5 |
|
M22 | 2.50 | 38 | 140 | 18 | 14.5 | |
| PM84-31-12100 | 13 |
|
M12 | 1.00 | 22 | 100 | 9 | 7 | |
| MG21-03050 | 1 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| MG21-04070 | 3 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| MG21-05080 | 4 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| MG21-06100 | 0 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| MG21-08100 | 0 |
|
M8 | 1.00 | 22 | 90 | 8 | 6.2 | |
| MG21-08125 | 5 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| MG21-12175 | 42 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| MG21-12150 | 20 |
|
M12 | 1.50 | 29 | 110 | 9 | 7 | |
| MG21-12100 | 9 |
|
M12 | 1.00 | 22 | 110 | 9 | 7 | |
| MG21-12125 | 19 |
|
M12 | 1.25 | 29 | 110 | 9 | 7 | |
| MG21-16200 | 67 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| MG21-16150 | 19 |
|
M16 | 1.50 | 32 | 110 | 12 | 9 | |
| MG21-24150 | 0 |
|
M24 | 1.50 | 45 | 160 | 18 | 14.5 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM81-31-04070 | 0 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| PM81-41-02040 | 162 |
|
M2 | 0.40 | 6 | 45 | 2.8 | 2.1 | |
| PM81-31-02040 | 152 |
|
M2 | 0.40 | 6 | 45 | 2.8 | 2.1 | |
| PM81-31-02545 | 116 |
|
M2.5 | 0.45 | 6 | 50 | 2.8 | 2.1 | |
| PM81-41-02545 | 144 |
|
M2.5 | 0.45 | 6 | 50 | 2.8 | 2.1 |
| Наименование | Склад | Обрабат. мат. | Резьба | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|
| M855-H10-G1/2 | 23 |
|
G1/2 | 30 | 80 | 16 | 12.5 | |
| M855-H10-G1/8 | 18 |
|
G1/8 | 18 | 55 | 8 | 6.3 | |
| M855-H10-G3/4 | 38 |
|
G3/4 | 30 | 80 | 18 | 14 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM87-31-03050 | 19 |
|
M3 | 0.50 | 6 | 56 | 3.5 | 2.7 | |
| PM87-31-04070 | 15 |
|
M4 | 0.70 | 9 | 63 | 4.5 | 3.4 | |
| PM87-31-05080 | 20 |
|
M5 | 0.80 | 10 | 70 | 6 | 4.9 | |
| PM87-31-06100 | 3 |
|
M6 | 1.00 | 12 | 80 | 6 | 4.9 | |
| PM87-31-08125 | 9 |
|
M8 | 1.25 | 15 | 90 | 8 | 6.2 | |
| PM87-31-10150 | 9 |
|
M10 | 1.50 | 18 | 100 | 10 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| PM88-31-12175 | 10 |
|
M12 | 1.75 | 21 | 110 | 9 | 7 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M830-H33-040070 | 2 |
|
M4 | 0.70 | 9 | 63 | 4.5 | 3.4 | |
| M830-H33-050080 | 8 |
|
M5 | 0.80 | 10 | 70 | 6 | 4.9 | |
| M830-H33-060100 | 23 |
|
M6 | 1.00 | 10 | 80 | 6 | 4.9 | |
| M830-H33-080125 | 33 |
|
M8 | 1.25 | 13 | 90 | 8 | 6.2 | |
| M830-H33-120175 | 0 |
|
M12 | 1.75 | 17 | 110 | 9 | 7 | |
| M830-H33-160200 | 14 |
|
M16 | 2.00 | 20 | 110 | 12 | 9 | |
| M830-H33-100150 | 0 |
|
M10 | 1.50 | 15 | 100 | 10 | 8 | |
| M830-H33-140200 | 11 |
|
M14 | 2.00 | 20 | 110 | 11 | 9 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M820-H21-090125 | 169 |
|
M9 | 1.25 | 22 | 100 | 10 | 8 | |
| M820-H21-020040 | 2 |
|
M2 | 0.40 | 8 | 45 | 2.8 | 2.1 | |
| M820-H21-030050 | 0 |
|
M3 | 0.50 | 11 | 56 | 3.5 | 2.7 | |
| M820-H21-040070 | 3 |
|
M4 | 0.70 | 13 | 63 | 4.5 | 3.4 | |
| M820-H21-050080 | 7 |
|
M5 | 0.80 | 16 | 70 | 6 | 4.9 | |
| M820-H21-060100 | 16 |
|
M6 | 1.00 | 19 | 80 | 6 | 4.9 | |
| M820-H21-080125 | 48 |
|
M8 | 1.25 | 22 | 90 | 8 | 6.2 | |
| M820-H21-100150 | 0 |
|
M10 | 1.50 | 24 | 100 | 10 | 8 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M821-H21-050080 | 0 |
|
M5 | 0.80 | 16 | 70 | 3.5 | 2.7 | |
| M821-H21-060100 | 252 |
|
M6 | 1.00 | 19 | 80 | 4.5 | 3.4 | |
| M821-H21-080125 | 45 |
|
M8 | 1.25 | 22 | 90 | 6 | 4.9 | |
| M821-H21-120175 | 25 |
|
M12 | 1.75 | 29 | 110 | 9 | 7 | |
| M821-H21-160200 | 0 |
|
M16 | 2.00 | 32 | 110 | 12 | 9 | |
| M821-H21-100150 | 0 |
|
M10 | 1.50 | 24 | 100 | 7 | 5.5 | |
| M821-H21-140200 | 11 |
|
M14 | 2.00 | 30 | 110 | 11 | 9 |
| Наименование | Склад | Обрабат. мат. | Резьба | Шаг резьбы | THL | Общая длина (L) | DCON | K | В корзину |
|---|---|---|---|---|---|---|---|---|---|
| M818-H11-120125 | 22 |
|
M12 | 1.25 | 29 | 89 | 9.0 | 7.1 | |
| M818-H11-180100 | 5 |
|
M18 | 1.00 | 22 | 97 | 14 | 11.2 |
